LK-U106 Implant Stability Meter

Product Item : LK-U106
Category： Implant & Piezosurgery
One-click Data Collection
No Consumables
Red, Yellow And Green Management
Product description：
INQUIRY Send Email

LK-U106 Implant Stability Meter

1. Intended use

It is a stability measuring device that uses tapping method, which measures the time of the Tapping Rod of the device contacting the implant for dentistry and dental implan-tology or oral cavity, or abutment, to measure the stability of the placed implant. The result of the measurement is displayed in iST scale (implant Stability Test), which is the numerical representation of the Implant Stability Test (iST) value, and higher scale represents greater implant stability or lower implant mobility. And the intended user is dentist and dental nurse.

2. Characteristics

①Convenient usage due to small and light design
②Easy to use due to simple controlling method
③Fast measuring time less than 3 seconds
④Safe measurement due to slight tapping technique and auto safety system (tapping
stops after tapping twice when Osseointegration is unstable, otherwise taps up to 6 times.)
⑤Available to check possibility of implant failure at in earlier stages

3.Technical Specifications
① Protection type against electrical shock: Class II
② Protection degree against electrical shock: Type B
③ Rechargeable lithium battery:
Battery model:16340, Battery capacity: 850mAh
Battery has over-voltage, over current and short circuit protection
④ Adapter
Input:100-240V~50/60Hz
Output: 5V 1A
⑤ Work condition:Environment temperature: +5°C to +40°C
Relative humidity: 10%~93%
